ROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGB

Brand Name : 2.4 Inch

Model Number : CH240QV29A-T

Certification : ROHS、ISO9001、CE

Place of Origin : ShenZhen, China

MOQ : 100 pcs

Price : /

Payment Terms : T/T

Delivery Time : 200Kpcs/month

Packaging Details : All the products are packed in right way to keep it safe. For small sizes of products we use tray + carton, For bigger sizes we use foam slot + carton. we also design packages according to customers' requirements

Module type : 2.4"TFT + RTP

Display Mode : TN/Transmissive/Normally white

Number of Dots : 240*3(RGB)*320

Viewing Direction : 6 o'clock

Module size : 42.72(W)*60.26(H)*3.5(T)mm

TFT Active area : 36.72(W)*48.96(H)mm

Interface : SPI、MCU、SPI+RGB

Luminace : 300cd/m2

Min. Order : 2 Pieces

Contact Now

2.4 inch ROHS certified Small LCD Touch Screen 240*320 Number of

Dots LCD module SPI / MCU / SPI + RGB TFT Screen Panel

1.Product Information

MODEL NO. CH240QV29A-T
Module type 2.4"TFT + RTP
Display Mode TN/Transmissive/Normally white
Number of Dots 240*3(RGB)*320
Viewing Direction 6 o'clock
Module size 42.72(W)*60.26(H)*3.5(T)mm
TFT Active area 36.72(W)*48.96(H)mm
Interface SPI,MCU,SPI+RGB
Luminace 300cd/m2

2. Product Description

ChengHao Display model CH240QV29A-T is a color active matrix thin film transistor

(TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device.

This model is composed of a TFT LCD panel, a driving circuit, a high brightness back-light,

a resistive touch screen and FPC.
The TFT display is a color active matrix thin film transistor (TFT) liquid crystal display

(LCD) that uses amorphous silicon TFT as a switching device. This TFT LCD has a 2.4 (4:3)

inch diagonally measured active display area with QVGA (240 horizontal by 320 vertical pixel)

resolution.
The driver used for this project is the ILITEK ILI9341V or compatible and can display

262K colors by 18 bit R.G.B. signal input. The driver is mounted on the glass and the

interconnection via FPC including components to drive the display module.
In addition, FPC can also be customized according to customer requirements, such as

modifying FPC structure, interface definition, etc.
RoHS Compliance & Halogen Free.

3.Product Drawings

ROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGBROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGB

4.Other Products

Module Type Display Area Display Mode
1.44 inch TFT LCD Display 25.50 * 26.50 mm Normally White IPS, Transmissive
1.44 inch TFT LCD Display 25.50 * 26.50 mm Normally White TN, Transmissive
1.50 inch TFT LCD Display 29.76 * 22.32 mm Normally Black IPS, Transmissive
1.54 inch TFT LCD Display 27.72 * 27.72 mm Normally Black IPS, Transmissive
1.54 inch TFT LCD Display 27.74 * 27.74 mm Normally Black IPS, Transmissive
1.77 inch TFT LCD Display 28.03 * 35.04 mm Normally White TN, Transmissive
1.80 inch TFT LCD Display 28.03 * 35.04 mm Normally White TN, Transmissive
2.00 inch TFT LCD Display 30.60 * 40.80 mm Normally White TN, Transmissive
2.10 inch TFT LCD Display Circular display area Normally White IPS, Transmissive
2.31 inch TFT LCD Display 46.75 * 35.06 mm Normally White TN, Transmissive
2.40 inch TFT LCD Display 36.72 * 48.96 mm Normally White TN, Transmissive
2.40 inch TFT LCD Display 36.72 * 48.96 mm Normally White IPS, Transmissive
2.80 inch TFT LCD Display 43.20 * 57.60 mm Normally White TN, Transmissive
2.80 inch TFT LCD Display 43.20 * 57.60 mm Normally White IPS, Transmissive
3.00 inch TFT LCD Display 36.72 * 65.28 mm Normally Black IPS, Transmissive
3.20 inch TFT LCD Display 48.60 * 64.80 mm Normally White TN, Transmissive
3.50 inch TFT LCD Display 70.08 * 52.56 mm Normally White TN, Transmissive
3.50 inch TFT LCD Display 70.08 * 52.56 mm Normally Black IPS, Transmissive
4.00 inch TFT LCD Display 51.84 * 86.4 mm Normally Black IPS, Transmissive
4.00 inch TFT LCD Display 71.86 * 70.18 mm Normally Black IPS, Transmissive
4.30 inch TFT LCD Display 95.04 * 53.86 mm Normally White TN, Transmissive
4.30 inch TFT LCD Display 95.04 * 53.86 mm Normally Black IPS, Transmissive
5.00 inch TFT LCD Display 110.88 * 62.83 mm Normally White TN, Transmissive
5.00 inch TFT LCD Display 108.00 * 64.8 0mm Normally Black IPS, Transmissive
5.50 inch TFT LCD Display 68.04 * 120.96 mm Normally Black IPS, Transmissive
6.00 inch TFT LCD Display 74.52 * 132.48 mm Normally Black IPS, Transmissive
7.00 inch TFT LCD Display 154.08 * 85.92 mm Normally White TN, Transmissive
7.00 inch TFT LCD Display 153.6 * 90 mm Normally White TN, Transmissive
7.00 inch TFT LCD Display 154.21 mm * 85.92 mm Normally Black IPS, Transmissive
8.00 inch TFT LCD Display 107.64 * 172.22 mm Normally Black IPS, Transmissive
9.00 inch TFT LCD Display 196.61 * 114.15 mm Normally White TN, Transmissive
10.10 inch TFT LCD Display 135.36 * 216.58 mm Normally Black IPS, Transmissive

5.Product Packaging

ROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGB

6.Express Shipping

ROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGB

ROHS FPC 2.4in Small LCD Touch Screen 240*320 SPI MCU RGBShenzhen Chenghao Optoelectronic Co.,Ltd

Mobile Phone :+86-775-27806536

WeChat/Whatsapp :Tina +15919862398

Skype : add@chenghaolcm.com

Email:add@chenghaolcm.com
